VTB V9600 Controller for Surron, Talaria & 79 Bikes
Controller Selection for Hall Sensor Compatibility
Surron Light Bee:
• With Original Motor: Requires Hall Sensor (6-Pin Square)
• With VTB Motor: No adapter needed / N/A
• With Third-Party Motor: Encoder (8-Pin Square) required for KO (Encoder), EBMX, Torp, or Sotion motors
• With Third-Party Motor (Hall Sensor): Requires Hall Sensor (6-Pin Square) for KO (Hall)
Surron Ultra Bee:
• With Original Motor: Requires Ultra Bee mount and adapter
• With VTB Motor: No adapter needed / N/A
• With Third-Party Motor: Compatibility TBD
Talaria Sting:
• With Original Motor: Requires Talaria Sting Motor Exclusive (8-Pin Square)
• With VTB Motor: No adapter needed / N/A
• With Third-Party Motor: Requires Talaria Sting Motor Exclusive (8-Pin Square)
Talaria X3:
• With Original Motor: TBD / Not supported
• With VTB Motor: No adapter needed / N/A
• With Third-Party Motor: Compatibility TBD
79 Bikes Falcon:
• With Original Motor: Compatibility TBD
• With VTB Motor: No adapter needed / N/A
• With Third-Party Motor (KO Encoder): Requires Encoder (8-Pin Square) for EBMX, Torp, or Sotion motors
• With Third-Party Motor (KO Hall): Requires Hall Sensor (6-Pin Square)
Controller Specifications
• Maximum Bus Phase Current: 500A/960A
• Peak Power: 44kW
• Operating Temperature Range: -25°C to 80°C
• Sinusoidal Vector Control
• Voltage Range: 30V-99V (Limit), 48V-84V (Operating)
Controller Features
• Fine-tunable throttle response
• High-reliability, redundant design
• Adaptive low-throttle compensation for low battery levels
• 3 power modes and 5 riding modes for quick switching
• 5 regenerative braking modes
• Linear regenerative electronic braking, saving up to 30% energy
• Customizable super-linear throttle handle and throttle curve, burst power, high-speed power compensation, and speed percentage
• Compatible with mainstream models: Light Bee, Ultra Bee, Talaria Sting, Talaria X3, 79 Bike Falcon
• Full-function app for Apple and Android
• High-resolution color screen instrument panel
• Sensory unlocking
• Bluetooth BMS binding for instrument panel
• CNC radiator
• IP67 waterproof for entire system
Package Contents
• Controller x1
• Color Screen Instrument Panel x1
• Instrument Panel Bracket x1
• Throttle Handle x1
• Switch Assembly x1
• Thumb Throttle x1
• Vehicle-specific Adapter Cable x1
Compatible Motors
• VTB Beast 28kW
• VTB Beast 35kW
• Sur-Ron Light Bee Factory
• Sur-Ron Ultra Bee Factory
• Talaria Sting Factory
• 79 Bike Falcon Factory
• QS165
• LTXS
• Sotion FW01
• Sotion Talaria
Compatible Batteries:
Series 16-22, compatible with various models of both factory and modified batteries.
VTB App: Real-time status
VTB App: Setup Guidance
VTB App: Basic & Advance Settings
